2026 Hyundai Santa Cruz Towing Capacity & Payload
The 2026 Hyundai Santa Cruz tows up to 5,000 pounds. To get there, you need the 2.5L turbocharged engine, HTRAC® All-Wheel Drive, trailer brakes, and proper towing equipment. Models with the standard 2.5L non-turbocharged engine are rated for up to 3,500 pounds with trailer brakes.
Payload is a different story. Every 2026 Santa Cruz carries the same 1,411-pound payload rating, from the entry SE to the top Limited. Stepping up a trim buys you equipment, not carrying capacity.
If you are shopping this truck to haul something specific, two numbers matter. The tow rating tells you which powertrain to pick. The payload rating tells you what you can actually load once the trailer is hitched.
Our team at Ontario Hyundai can help you match a Santa Cruz configuration to what you plan to pull. Stop by the showroom at 1307 Kettering Dr, Ontario, CA 91761, or call our sales team at 888-653-8231.
Maximum towing and payload capacity figures are based on properly equipped vehicles and vary by configuration. Do not exceed any weight rating. See your owner’s manual and the vehicle’s door-jamb label for specific capacities.
2026 Santa Cruz Towing and Payload at a Glance
| Maximum towing (with trailer brakes) | 5,000 lbs — XRT and Limited |
|---|---|
| Towing, naturally aspirated trims | 3,500 lbs — SE, SEL, SEL Activity |
| Payload rating | 1,411 lbs — identical on all five trims |
| Bed volume | 27.0 cu ft — identical on all five trims |
| Seating capacity | 5 passengers |
| Trailer pre-wiring | Standard on every trim |
Maximum towing and payload capacity figures are based on properly equipped vehicles and vary by configuration. Do not exceed any weight rating. See your owner’s manual and the vehicle’s door-jamb label for specific capacities.
Which 2026 Santa Cruz Powertrain Reaches the 5,000-lb Towing Limit?
Turbocharged XRT and Limited
Only the XRT and Limited trims tow 5,000 pounds. Both come standard with the 2.5L turbocharged four-cylinder, which produces 281 horsepower and 311 lb-ft of torque. HTRAC All-Wheel Drive is standard on both, and front-wheel drive is not offered on either trim.
Naturally Aspirated SE, SEL, and SEL Activity
These three trims use the naturally aspirated 2.5L four-cylinder, rated at 191 horsepower and 181 lb-ft of torque. All three tow up to 3,500 pounds with trailer brakes. That rating holds in front-wheel drive and with available HTRAC All-Wheel Drive, so adding AWD does not raise it.
Why the Torque Gap Matters
The gap between the two engines is 130 lb-ft. Where that torque arrives matters as much as how much of it there is. The turbocharged engine holds peak torque from 1,700 rpm through 4,000 rpm, while the naturally aspirated engine reaches its peak at 4,000 rpm. That low-end spread is what you feel launching a boat up a steep ramp, or holding 65 mph on a highway grade with a trailer behind you.
All five 2026 trims use an 8-speed automatic transmission with SHIFTRONIC®. Tow Mode is standard on the XRT and Limited, and is not offered on the naturally aspirated trims.
You can see how the trims line up in the 2026 Santa Cruz overview. Drivers weighing the HTRAC option can also review which Hyundai vehicles offer all-wheel drive.
Maximum towing and payload capacity figures are based on properly equipped vehicles and vary by configuration. Do not exceed any weight rating. See your owner’s manual and the vehicle’s door-jamb label for specific capacities.
2026 Santa Cruz Towing, Payload, and Curb Weight by Trim
| Trim | Engine | Horsepower / Torque | Drivetrain | Curb Weight (lbs) | Max Towing w/ Trailer Brakes | Payload |
|---|---|---|---|---|---|---|
| SE | 2.5L I4 | 191 hp / 181 lb-ft | FWD standard, HTRAC AWD available | 3,779 FWD / 3,922 AWD | 3,500 lbs | 1,411 lbs |
| SEL | 2.5L I4 | 191 hp / 181 lb-ft | FWD standard, HTRAC AWD available | 3,805 FWD / 3,948 AWD | 3,500 lbs | 1,411 lbs |
| SEL Activity | 2.5L I4 | 191 hp / 181 lb-ft | FWD standard, HTRAC AWD available | 3,900 FWD / 4,043 AWD | 3,500 lbs | 1,411 lbs |
| XRT | 2.5L I4 Turbo | 281 hp / 311 lb-ft | HTRAC AWD standard | 4,140 | 5,000 lbs | 1,411 lbs |
| Limited | 2.5L I4 Turbo | 281 hp / 311 lb-ft | HTRAC AWD standard | 4,191 | 5,000 lbs | 1,411 lbs |
Figures above are drawn from Hyundai’s published 2026 Santa Cruz specifications.
Maximum towing and payload capacity figures are based on properly equipped vehicles and vary by configuration. Do not exceed any weight rating. See your owner’s manual and the vehicle’s door-jamb label for specific capacities.
Why Payload Matters More Than the Tow Rating
Payload is the total weight a vehicle can carry. It counts three things together: passengers, whatever is in the bed, and the downward tongue weight of a trailer resting on the hitch.
Tongue weight is subtracted from payload, not from the tow rating. That is why the 1,411-pound figure is usually the number that limits a real trailering setup — not the 5,000-pound headline.
This is also where the 2026 Santa Cruz behaves differently from most trucks. Payload does not vary by trim. Higher trims add weight in comfort, technology, and convenience equipment, so curb weight climbs. Even so, Hyundai publishes the same 1,411-pound rating across the entire lineup.
Bed volume is likewise identical everywhere in the lineup at 27 cubic feet. The sheet-molded composite bed and lockable under-bed storage compartment are standard on all five trims.
Before you load up, check the certification label on your driver’s door jamb. That label reflects the specific vehicle in front of you, including any equipment added at the port or by the dealer.
Maximum towing and payload capacity figures are based on properly equipped vehicles and vary by configuration. Do not exceed any weight rating. See your owner’s manual and the vehicle’s door-jamb label for specific capacities.
Does the 2026 Santa Cruz Come With a Trailer Hitch?
The 2026 Santa Cruz does not include a receiver hitch as standard equipment. Hyundai offers a Tow Hitch with a 2-inch receiver as a Hyundai Genuine Accessory, fitted at the port or by the dealer, with the tow harness sold separately.
Factory trailer pre-wiring is standard on every trim. The SE and SEL get a 4-pin harness. The SEL Activity, XRT, and Limited get a 4- or 7-pin configuration.
How to Verify a Specific Vehicle’s Tow Equipment
Start with the original window sticker, also called the Monroney label. You can also ask our team to run the VIN. The factory label details installed options, including whether an OEM receiver hitch was fitted as a port-installed or dealer-installed accessory.
You can also inspect the rear of the vehicle directly. Integrated rear bumper steps are standard across the lineup. If a hitch has been installed, the receiver and the wiring-harness bracket sit beneath the center of the bumper.
Trailer Brakes and Brake Controllers
The Santa Cruz does not list a factory-integrated trailer brake controller among its standard equipment. If your trailer has electric brakes, plan on a brake controller being wired into the cabin.
What the 2026 Santa Cruz Is Built to Pull
Hyundai markets the Santa Cruz as a Sport Adventure Vehicle rather than a conventional pickup, and the tow ratings reflect that positioning. It is built for recreational gear, not heavy-duty work loads. Typical matches include:
- Lightweight teardrop campers
- Pop-up trailers
- Utility trailers
- Small boat trailers
Self-Leveling Rear Suspension
Standard on all five trims. It adjusts rear ride height automatically when weight is placed on the tow ball, which keeps the truck sitting level under load.
Sheet-Molded Composite Bed
Standard across the lineup at 27 cubic feet, with a lockable under-bed storage compartment for stowing gear out of sight.
Cargo Tie-Down Hardware
Heavy-duty cargo D-rings and sidewall bed storage compartments are standard on every trim.
2026 Santa Cruz Tow Equipment by Trim
A 115V power outlet and a factory-integrated tonneau cover with T-slot utility tracks are standard on the SEL Activity, XRT, and Limited.
| Trim | Tow Mode | Trailer Pre-Wiring | Integrated Tonneau Cover | 115V Bed Outlet |
|---|---|---|---|---|
| SE | Not offered | Standard 4-pin | Not offered | Not offered |
| SEL | Not offered | Standard 4-pin | Not offered | Not offered |
| SEL Activity | Not offered | Standard 4 or 7-pin | Standard | Standard |
| XRT | Standard | Standard 4 or 7-pin | Standard | Standard |
| Limited | Standard | Standard 4 or 7-pin | Standard | Standard |
Equipment availability above reflects Hyundai’s published 2026 Santa Cruz specifications.
Santa Cruz Towing Around Ontario and the Inland Empire
The Santa Cruz is a practical fit for drivers across Ontario, Fontana, Rancho Cucamonga, Corona, and Eastvale. That might mean a utility trailer on a weekend project. It might mean gear stowed in the bed after a morning at the North Etiwanda Preserve.
Hyundai’s quality record backs the truck up. The Santa Cruz ranked highest in the Midsize Pickup segment in the J.D. Power 2026 U.S. Initial Quality Study. That is its third consecutive segment win, measured in problems per 100 vehicles during the first 90 days of ownership.
For J.D. Power 2026 award information, visit jdpower.com/awards.
Frequently Asked Questions About 2026 Santa Cruz Towing
Does the 2026 Santa Cruz include a built-in trailer brake controller?
No. A factory-integrated trailer brake controller is not listed among the Santa Cruz’s standard equipment. While the SEL Activity, XRT, and Limited include 4- or 7-pin trailer pre-wiring from the factory, a brake controller must be wired into the vehicle if you plan to pull a trailer equipped with electric brakes.
Which trims have Tow Mode?
Tow Mode is standard on the turbocharged XRT and Limited trims. It is not offered on the SE, SEL, or SEL Activity.
What warranty coverage backs the 2026 Santa Cruz?
Every 2026 Santa Cruz is covered by a 5-year/60,000-mile new vehicle limited warranty and 5 years of unlimited-mileage 24/7 roadside assistance. The 10-year/100,000-mile powertrain limited warranty applies to the original owner only; second and subsequent owners receive powertrain coverage under the 5-year/60,000-mile new vehicle limited warranty.
Warranty terms above are drawn from Hyundai’s published 2026 Santa Cruz specifications.
This information is provided for general educational purposes only and does not constitute legal advice. Warranty coverage depends on the specific terms of your vehicle’s warranty agreement. Consult your owner’s manual or a qualified legal professional for guidance on your individual situation.
Explore the 2026 Hyundai Santa Cruz at Ontario Hyundai
The 2026 Santa Cruz blends crossover comfort with pickup utility. Its towing setup covers most recreational hauling without the size or running costs of a full-size truck. Whether you need an efficient daily driver or a capable rig for a lightweight camper, our team can help you configure the right powertrain and equipment.
Visit our showroom at 1307 Kettering Dr, Ontario, CA 91761, or call 888-653-8231 to talk through your trailering plans with our sales team.
